Svets, Löd, Gasol, Utsug

Argon welding glove of soft goatskin with top and collar (12 cm) of split leather. Unlined and sewn with Kevlar thread. Length 30-35 cm. Lanolin- and DMFu-free.

Approved/Certified according to:
EN ISO 21420:2020
EN 388:2016 2132X
EN 407:2020 41214X< BR>EN 12477:2001+A:2005: (Type B)

Welding and cut protection glove lined with Kevlar that protects against cuts. Made of high-quality goat grain and goat split and sewn with Kevlar thread.

Approved/Certified according to:
EN 388:2016-2132D
EN 420, EN 407:2004 -41214X
EN 12477:2001+A:2005 Type B

Contact nozzle Binzel, M6 and M8.
This contact tube is made of pure electrolytic copper and has a Vickers hardness (HV) of about 110 to 115. The purity of copper ensures very good current transfer, heat transfer and thermal conductivity. Since it already softens at a temperature of about 260°C, it is more suitable for low ampere ranges.

Electrode for welding cast iron and joining cast iron with steel.

Electrode for welding aluminum and its alloys. Also castings.

BV 12 has a low weight and does not hinder work with gas welding and/or gas torches. The pressure drop in the check valve is insignificant. Can be used up to 16 bar and in the temperature range -30ºC to 50ºC. The check valve is marked with gas type, flow direction, maximum working pressure and manufacturer.
NOTE! The non-return valve does not replace the non-return valve.

Protects the welder from continuous kickback, backflow and fire when welding and cutting. Must always be used for fuel gases and propane and recommended for oxygen. Since oxygen increases the combustion rate, a backstop should also be fitted to the oxygen regulator.
Designed for the following gases: Acetylene, hydrogen, propane, methane, MAP gases and oxygen.
With five important safety features:
-Shuts off gas supply in case of continuous backflow.
-Stops and extinguishes continuous backflow.
-Prevents backflow.
-Shuts off gas supply in case of overheating (95°C).
-Simple and effective reset function.

Coupling for connection of regulator to 5 liter acetylene bottle.

Blowtorch for both professionals and home craftsmen. For soldering, paint removal, bolt loosening and other heat applications. SoftGrip handle and automatic Piezo ignition. Standard burner that provides a stable and windproof flame. AntiFlare function, can be used in any position. Used together with Powergas 2203.
Gas container not included.
Gas container - Extremely flammable.

Blowtorch equipped with a sturdy handle and with gas container 2203 (containing a mixture of propane/butane). Supplied with standard torch suitable for soft soldering, minor brazing, paint removal, thawing and other heat work.
8844: Tip torch for precision work such as gold or silversmithing.
8846: Flat burner nozzle for e.g. paint removal and ski walling. With a powerful wide flame for effective outdoor work.
Contains butane/propane gas. Extremely flammable.

Set consisting of burner head, standard burner, LPG container (2204) and container base. The burner head has a control valve and bayonet mount for quick replacement of different burners. Automatic ignition - the flame is switched on and off with the push button. Also with locking button for long intervals or when you want to keep your hands free.
LPG container - Extremely flammable.

Efficient blowtorch with double-injected composite handle for maximum comfort and ease of use. Built-in automatic ignition - the flame is switched on and off with the push button. Lock button for long intervals or when you want your hands free. Burner with bayonet mount for quick change between different burners. Shut-off valve. Supplied complete with handle and cyclone burner 8706 suitable for all types of heating work incl. soldering of pipes.
253501: For refillable propane bottle P 2000. For professional users e.g. plumbing, air conditioning, paint removal and shrinking.
253511: For disposable containers 2205, 2206 or 2208.
Gas containers - Extremely flammable.

(HTML text not available)

Burner for easier soldering and heating work. Fits together with throat tube 8716 and refillable LPG bottle 2000.

Efficient burners for Sievert Metal Jet and Power Jet.
Cyclone burner 8707 only fits Metal Jet and Power Jet Ultra.

For connection to burner handle 3486 or 3488. Recommended working pressure 2-4 bar, but the design allows direct bottle pressure, but hose break valve must then be used. The burners are perfect for drying and welding cardboard, detail work, road work and other demanding heat work such as asphalt work, insulation, preheating, melting ice and snow. In the case of reradiation heat, longer throat tubes should be used.
Burners 294102, 294202, 294302, 294402 made of brass. Burners 293401 and 296001 made of stainless steel.

Highly efficient cyclone torch for hard and soft soldering. The rotating flame provides an even distribution of heat around the workpiece. For direct connection to the Sievert Pro handle.

Burners for soft soldering and gold or silver forging and other minor heat work. Neck pipe is connected between burner handle and burner. Thread towards burner M20x1. Thread to handle G (R) 3/8" right.
Burner 884204 only for neck tube 350101. For connection to burner handle 3486 or 3488.

Ergonomic burner for heating work. Made of titanium, which gives 60% less weight compared to traditional burners. To be used with Pro handle. Short burner for detail work. Long burner for heavier work.

Heat-resistant polypropylene handle. The control valve precisely regulates the gas flow for both small and large burners. Thread to throat tube G (R) 3/8 ¨ right. Thread to hose coupling G (R) 3/8 ¨ left.

Equipped with an economy flame valve, which saves time and gas and provides a precise and easily adjustable economy flame that can be quickly changed to full flame by pressing the button on the valve. The button can also be locked at full flame and quickly changed to economy flame. Thread to throat tube G (R) 3/8¨ right. Thread to hose coupling G (R) 3/8 ¨ left.

Burner handle in ergonomic design with automatic ignition and extinguishing function. Bayonet mount for easy and quick torch change. Rotating connection to avoid hose entanglement. Equipped with suspension hook and footrest. Brass knob for fine-tuning the flame. Wide range of burners for all applications. Connection thread R3/8"V.
For use with propane or butane gas.
Sievert ProMatic always requires regulator.

For hard or soft soldering. For connection to P-bottle. Contains cyclone burner 3335, handle 3366, 4 meter hose with reducing valve 309121 with fixed pressure 2 bar.
Sievert ProMatic always requires regulator.

Very easily welded omni-current electrode. Excellent thin plate electrode and the good flowability mean that both butt and fillet welds have an even and beautiful string appearance. Lightly ignites even with small transformers with 50 V open-circuit voltage (OCV). OK 43.32 is recommended for ordinary carbon steel, as well as for ship steel of A quality in ordinary strength class.
Return: 95%
Current type: DC+(-), AC , open-circuit voltage (OCV) 50 V
Examples of corresponding additive materials:
TIG: OK Tigrod 12.64 MAG: OK Autrod 12.50, 12.51, 12.64 Tube wire: OK Tubrod 15.14; PZ6113
Electrode class:
SFA/AWS A5.1: E6013 EN ISO 2560-A: E 42 0 RR 12
Typical values ??of solid welds:
Chemical composition %:
C: <=0.12, Si: 0.55, Mn: 0.5
Mechanical values:< BR>Strength (ReL): 460 MPa
Strength of rupture (Rm): 550 MPa
Elongation (A5): 26%
Impact toughness, KV:
Test temperature/Impact toughness value:
+20°C/65 J, 0°C/=>47 J
Approvals:
ABS: 2, BV: 1, DB: 10.039.36, DNV: 2, GL: 1, LR: 1, VdTÜV: 00621, CE: EN13479, RS: 2

(HTML text not available)

(HTML text not available)

Extra low-carbon stainless steel electrode of type 18Cr 12Ni 2.8Mo intended for position welding mainly of thin-walled pipes. The electrode has a thin casing and can be welded according to the so-called ''drop welding method'' or vertical falling, which is faster. This requires an electrode with very good ignition and re-ignition properties, which makes OK 63.20 very suitable. The electrode is directly adapted for the stainless steels of types 316 and 316L, for example X3CrNiMo17-13-3 (SS2343), X2CrNiMo18-14-3 (SS2353) or corresponding steel according to other standards. The weld metal's low carbon content provides good resistance to intercrystalline corrosion but also to pitting and most types of corrosion in reducing and neutral solutions. OK 63.20 can also be used for welding stabilized steels if these are not to be operated at temperatures above 400°C. /B>
DC+, AC, open-circuit voltage (OCV) 50 V
Examples of corresponding additive materials:
TIG: OK Tigrod 16.32
MAG: OK Autrod 16.32
Tubing wire: OK Tubrod 14.21
Electrode class:
EN 1600: E 19 12 3 L R 1 1
SFA/AWS A5.4: E316L-16
Werkstoff Nr: 1.4430
CSA W48: E316L-16
Typical values ??of all-weld material:
Chemical composition %:
C: <0.03, Si : 0.50-1.00 Mn: 0.5-1.2, Cr: 17.5-19.0, Ni: 11.0-13.0, Mo: 2.5-3.0
Mechanical values:
Yield limit (Rp0 ,2): 480 MPa
Breaking strength (Rm): 590 MPa
Elongation (A5): 41%
Impact toughness, KV:
Test temperature/Impact toughness value: +20° C/56 J, -60°C/46 J
Ferrite number: FN 3-10
Approvals:
CWB: CSA W48, Seproz: UNA 272580, VdTÜV: 09716, CE: EN 13479

(HTML text not available)

Basic low-hydrogen electrode that is distinguished by its exceptional welding properties. Due to the double-sheathed casing, the electrode is very easily welded within a wide current range, i.a. very secure against "tapping". A stable arc in very low current ranges. The electrode is very easy to strike and produces straight to concave welds in fillet welds.
Materials
SIS steel
1232, 1370, 1450, 2116, 2146, 2121, 2165, 1300, 1411 , 1505, 2122, 2172, 1305, 1412, 1550, 2132, 2174, 1306, 1414, 1572, 2133, 1311, 1426, 2134, 1312, 1430, 2101, 2136, 1316, 1432, 2103, 2142, 1330, 1434 , 2106, 2143, 1360, 1435, 2108, 2144
Type of current
Direct current + or - pole, Alternating current
Similar additive material
Wire electrode: SG2, NERTALIC 70A
Tube electrode: FLUXOFIL M8, M10, FLUXOFIL 30, 31,
FLUXOFIL 19HD, SAFDUAL 100
Electrode type
Basic< BR>Yield: c:a 105%
Redrying: 2 h 300-350 °C
Weld goods analysis
C : 0.06, Si: 0.7, Mn: 0.9
Mechanical properties
Untreated weld metal:
Tensile strength N/mm²: > ;=380
Breaking strength N/mm²: 470-600
Elongation L=5xD %: >=20
Impact strength Charpy-V °C : +20: 150J
Impact strength Charpy-V °C : -20: 100J
Approvals
American Bureau of Shipping 3HH, 3Y
Bureau Veritas 3,3YHH
Det Norske Veritas 3YHH
Lloyd's Register of shipping 3, 3YH
Germanischer Lloyd 3YHH
TÜV Kennblatt Nr 0061.07
Norms
Swedish Standard 143209H10
SS-EN 499 E 38 2 B 12 H10
AWS-ASME SFA 5.1 E 7016
DIN 1913 E 51 43 B (R) 10

Electrode holder Optimus is of crocodile type with encapsulated electrode attachment. For increased flexibility, the electrode can be attached both horizontally and vertically. The holder is completely insulated and made of fiberglass reinforced plastic. CE-approved.
Max amperage refers to 60% intermittence.

Electrode holder Prima is of the crocodile type with encapsulated electrode attachment, fully insulated and CE-approved.
Max current strength is intended at 35% intermittency.

Light and compact fan unit that provides continuous air flow to the welding helmet. With QRS coupling for easy handling of the air hose. The design allows any combination of particle and gas filters for protection against specific organic, inorganic and acid gases. You can change the particle filter or the gas filter as needed. No external batteries, no battery cables and no sharp edges. Particle filter indicator shows how much filter capacity you have left. The batteries can be charged either on site in the fan unit or separately.
Used together with 3M Speedglas welding helmets prepared for Adflo. Adapter included to also fit the 9000 series.

Levereras med

• Fläktenhet
• Partikelfilter
• Förfilter
• Gnistskydd
• Filterskydd
• Flexibel luftslang 90-125cm
• Heavy-Duty Batteri
• Universalladdare
• Komfortbälte
• Axelremmar
• Flödesmätare

Hjälm köps separat.

Footrest that fits all burners. Simple assembly.

Friskluftspaket Supplied AIR för tryckluft

Levereras med

• Luftenhet
• Flexibel luftslang 90-125cm
• Flödesmätare
• Komfortbälte

Burner in small format.

Gas burner with automatic ignition. Powerful flame that can be adjusted in both shape and intensity. Powered by butane gas. Metal handle. Fixed support foot that makes it stable during "hands free" work. The stable flame can be adjusted both in shape and intensity. Suitable for e.g. cooking (painting, flaming), soldering, shrinking work, melting/thawing snow and ice, lighting bonfires, lighting and marshals, etc. Supplied without gas. Flame temperature 1350°C. 200 min burning time per filling.

Gas cylinder gaskets.

Test flow meter for gas arc welding for MISON, argon and argon mixtures with carbon dioxide.
